3D Printing
3D printing that moves from concept to physical part with the right production path.
Combines large-volume and high-definition 3D printing in one commercial offer so the client thinks about the outcome, not the underlying technology.
Process specifications
Large-format envelope
80 x 80 x 100 cm
High-detail resin volume
22.3 x 12.6 x 23.5 cm
XY resolution
16.8 x 24.8 um
Higher-volume resin envelope
33 x 18.5 x 40 cm
- Large-format build volume: up to 80 x 80 x 100 cm for oversized parts.
- High-definition resin volume: 22.3 x 12.6 x 23.5 cm with 16.8 x 24.8 um XY resolution.
- Larger-volume resin output: 33 x 18.5 x 40 cm with 43 um XY resolution.
- Engineering-material route for PETG, ABS, ASA-CF, and flexible materials depending on end use.
Materials
- PLA
- PETG
- ABS
- ASA-CF
- TPU
- Standard resins
- High-detail resins
Technical process details
Combines volume-oriented output with enclosed printing for engineering materials and a high-definition route for parts where finish matters more.
Can cover everything from functional prototypes and repeatable parts to large-format components and fine-detail masters.
Flexible and technical materials are selected according to temperature, mechanical load, finish expectations, and delivery speed.
Typical outcomes
- Functional prototypes
- Visual parts
- Short runs
- Masters and presentation models
FDM
The FDM route is built for functional parts, rapid validation, short runs, and large-format components where scale, part cost, and production speed matter more.
- Large-format capacity up to 80 x 80 x 100 cm.
- Enclosed path for engineering materials such as PETG, ABS, ASA-CF, and TPU depending on the application.
- Good scalability for multiple parts at once and batch-oriented delivery.
Resin
The resin route is used when surface detail, fine visual reading, and presentation quality matter more than part cost or maximum size.
- 22.3 x 12.6 x 23.5 cm high-definition volume for smaller, detail-heavy parts.
- 33 x 18.5 x 40 cm volume for taller parts or small batches with better finish quality.
- XY resolutions down to 16.8 x 24.8 um for masters, miniatures, and presentation-grade parts.
Process capabilities
FDM
Fused Deposition Modeling optimized for rapid prototyping, functional parts, and large-format manufacturing using the Bambu Lab ecosystem and oversized printers.
Minimum lead time
1-3 days
General tolerances
±0.2 mm for the first 10 mm, ±0.05 mm per additional mm
Standard max part size
256 x 256 x 256 mm
Large-format max size
800 x 800 x 1000 mm
Minimum feature
0.4 mm with 0.2 mm nozzle, recommended >0.6 mm
Minimum wall
1.0 mm recommended, 0.8 mm minimum
Layer thickness
0.08 - 0.32 mm depending on quality
Guaranteed tolerances
Get custom quote
High-speed printing with the Bambu Lab ecosystem.
AMS support for multi-material and color workflows.
Large-format output available for oversized parts.
SLA
High-resolution resin printing for visual prototypes, detail-heavy parts, and small-batch production with smoother surfaces.
Minimum lead time
1-3 days
XY tolerances
±0.05 to 0.1 mm
Z tolerances
±0.1 to 0.2 mm
Standard max part size
218 x 123 x 235 mm
Large-format max size
330 x 185 x 400 mm
Minimum feature
0.2 - 0.3 mm
Minimum wall
0.4 mm supported / 0.6 mm unsupported
Layer thickness
0.02 - 0.1 mm
Guaranteed tolerances
Get custom quote
Ultra-high 14K resolution.
Smoother surface finish.
Ideal for molds, miniatures, and visual prototypes.
Technical material table
| Material | Process | What it adds | Best use |
|---|---|---|---|
| PLA | FDM | Fast, accessible, and easy to prototype with | Models, form studies, early prototypes |
| PETG | FDM | Better strength and stability than PLA | Functional parts, fixtures, light-duty components |
| ABS | FDM | Higher thermal and mechanical resistance | Housings, technical parts, functional validation |
| ASA-CF | FDM | More rigidity and stronger performance for demanding environments | Engineering parts, supports, higher-demand applications |
| TPU | FDM | Flexibility and impact absorption | Seals, guards, flexible parts |
| Standard resin | Resin | Good detail and visual quality | Masters, visual parts, presentation pieces |
| Tough resin | Resin | Better mechanical behavior than brittle resin | Small visual-functional prototypes |
| High-detail resin | Resin | Very fine surface detail | Miniatures, jewelry, display-grade parts |
Materials and properties
FDM
| Material | Description | Tensile strength | Elongation | HDT |
|---|---|---|---|---|
| PLA | General purpose prototyping | 50-60 MPa | 2-6% | 50-60°C |
| PETG | Durable and chemically resistant | 45-55 MPa | 10-25% | 70-80°C |
| ABS | Impact resistant for engineering use | 30-45 MPa | 5-20% | 90-105°C |
| ASA | UV resistant for outdoor use | 30-45 MPa | 5-20% | 95-105°C |
| TPU | Flexible material | 20-40 MPa | 200-500% | 60-80°C |
| Nylon (PA6 / PA12) | High strength and wear resistance | 50-75 MPa | 20-100% | 120-160°C |
| Carbon Fiber Reinforced | High stiffness and lower weight | 60-110 MPa | 1-5% | 100-160°C |
| Polycarbonate (PC) | High temperature resistance | 60-70 MPa | 5-10% | 110-140°C |
| PC-ABS | Impact plus heat resistance | 40-60 MPa | 5-10% | 100-120°C |
SLA
| Material | Description | Flexural strength | Elongation | HDT |
|---|---|---|---|---|
| Standard Resin | General purpose visual parts | 40-70 MPa | 5-10% | 50-60°C |
| ABS-like Resin | Tougher functional prototypes | 60-80 MPa | 10-25% | 60-80°C |
| Tough Resin | Impact resistant | 50-70 MPa | 20-50% | 50-70°C |
| High Temp Resin | Heat resistant applications | 70-120 MPa | 1-5% | 120-200°C |
| Flexible Resin | Rubber-like behavior | 5-15 MPa | 50-150% | 40-60°C |
| Castable Resin | Investment casting applications | N/A | Low | Varies |
What this can achieve
When FDM is the better route
FDM is the stronger path when you need bigger parts, functional prototypes, small batches, or a more efficient cost-to-volume ratio. It is also the right choice for fixtures, props, architecture, mechanical validation, and components where extreme detail is not the top priority.
When resin is the better route
Resin is the better fit when the part needs to look cleaner, hold finer detail, or work as a presentation master. It is especially useful for miniatures, small parts, jewelry, display objects, and visual prototypes where visible layer texture needs to be minimized.
What people usually underestimate
3D printing is not only for 'mockups'. It can produce functional validation parts, spare parts, light tooling, commercial presentation components, molds, props, architectural pieces, and small runs for selling or market testing.
